ABB 88TK05C-E GJR2393200R1220 Bus Coupling Module
Key SpecificationsVOGI
1.Product category: AC800M series controller, supports redundant configuration
2.Processor: MPC860 PowerQUICC II (300 MHz)
3.Memory: 16 MB RAM + 16 MB Flash
4.Communication protocol: PROFIBUS DP-V1 (V1.0 version), Modbus TCP (supports function codes 01/02/03/04/05/06/15/16), EtherNet/IP (CIP protocol)
5.Power supply voltage: 24 VDC (±10%), supports redundant power supply
6.Power consumption: typical 12 W (24 VDC, 500 mA)
7.Operating temperature: -25℃ to +60℃
8.Protection level: IP20 (indoor installation)
Key FeaturesVOGI
1.Station bus protocol: ABB 88TK05C-E GJR2393200R1220 supports real-time data transmission, the data frame format is 8-bit data + 1-bit parity + 2-bit stop bit, and the maximum transmission distance is 1 km (twisted pair).
2.Redundant design: ABB 88TK05C-E GJR2393200R1220 uses dual-port RS-485 to support line redundancy, and the fault switching time is < 100 μs.
3.I/O expansion: 32 I/O modules (such as AI815, DO820) can be expanded through the TU830 terminal unit, and hot swapping is supported.
4.Cross-system compatibility: ABB 88TK05C-E GJR2393200R1220 supports third-party PLCs (such as Siemens S7-300) through GSD files.
5.LED indicator: ABB 88TK05C-E GJR2393200R1220 displays module status (operation, fault, communication error) in real time.
6.Remote management: ABB 88TK05C-E GJR2393200R1220 supports parameter configuration and firmware upgrade to reduce maintenance costs.
7.EMC certification: ABB 88TK05C-E GJR2393200R1220 complies with IEC 61000-6-4/6-2 electromagnetic compatibility standards.
8.Environmental certification: ABB 88TK05C-E GJR2393200R1220 is UL 508 certified for industrial control equipment and supports RoHS directive.
