ABB DAO01 P3717-4-0369629 Analog Output Module

Analog output: 4-20 mA or 0-10 V

Resolution: 16 bit high resolution.

Accuracy: ±0.1% full scale

Load Resistor Capacity: The maximum load resistance is 500 omega

Voltage output mode: Drive capability -- 5 mA

Communications: Such as Profibus DP, Modbus RTU etc.

Voltage of operation: 24 V DC (+10, -10%)

Power: Usually < 5 W

Temperature operation:-25°Cto+60°C

Protection class: IP20 For installation inside cabinet

Pinpoint accuracy stability: Only high–resolution DAC and temperature compensation technology could provide the level of long–term stability of ABB DAO01.

Abb da01 is modular ABB DA 01 support hot installation,Easy to increase or replace modules, reduce switch down time.

Anti-jamming: designed with electric isolation and filtering, ABB DAO01 can be used in the industrial field with strong electromagnetism interference.

Diagnose function: there are LED indicators on ABB DAO01 to show the module status (including power supply, communication, channel fault) in real-time.

Compatibility: ABB DAO01 is compatible with ABB automation systems (e.g. AC500 PLC series) and a variety of different bus protocols.

Flexible setting: Output range can be set freely through software according to demand of equipment.

ABB DAO01 can control regulating valves, flow meters, pressure transmitters and other equipment.

Example: In the chemical reactor, the 4-20 ma signal from the ABB DAO01 is sent to control the valve opening size, precise control flow, pressure of the reaction part of the material.

Part of the reclaimed water used for perennial greening is from automobile washdown.

Function: Drive to inverter or servo motor to regulate speed or position of production line.

Example: ABB DAO01 in automobile painting booths sends 0-10 V signals to control inverters and change the speed of conveyor belts to adapt to the spraying rhythm of different models.

Energy management applications (e.g. water treatment systems, power systems) ​

For example, DAO01 manages the velocity of water pumps at sewage treatment plant and changes the discharge volume adaptively for the water level sensors feedback.

Function: Can regulate the damper opening of the air-conditioning, adjustable brightness, etc.

Example: The smart building of the Energy Field, using exchanger's refrigeration system and the HVAC system to control the damper by DAO01's outputting of the analog control signal, realizes accurate temperature and humidity regulation.

Pharma & Food Stuff and Food & Beverages

Function: Control the equipment to fill and control the temperature.

Example: ABB DAO01 adjusts the opening of the steam valve by means of the DAO01 output signal to maintain the temperature at a constant level during the sterilizing process in pharmaceutical production lines.
