ABB EI813F 3BDH000022R1 Ethernet Fieldbus Module

Interface type: 10/100Mbit/s adaptive Ethernet interface with RJ45 connector.

Protocol support: Support TCP/IP, UDP, Modbus TCP and other protocols, easy to communicate with a variety of industrial equipment.

Network topology: supports star, bus and other network topologies, which is convenient to build a flexible industrial network.

Power supply voltage: 24V DC (±10% fluctuation allowed), low power consumption.

Insulation resistance: the insulation resistance between power supply and communication interface is not less than 100MΩ.

Voltage resistance: the power supply and communication interface can withstand 1500V AC for 1 minute.

Operating temperature: -20°C to +60°C, can adapt to the more severe industrial environment temperature.

Storage temperature: -40°C to +85°C.

Humidity range: 5% - 95% relative humidity, non-condensing.

Dual-port redundant design: Two 10BaseT (RJ45) Ethernet ports are available for ABB EI813F, which can provide network redundant configuration and ensure communication continuity under critical industrial scenarios.

Built-in protocol compatibility: ABB EI813F directly supports the mainstream industrial protocols like TCP/IP, Modbus TCP, etc., can be seamlessly connected to third-party PLC/DCS systems and ABB AC500 PLC for remote control and data collection.

Wide temperature anti-interference: the operating temperature range -20°C~+60°C, EMC certiifed adapt to metallurgy,chemical and other harsh environments.

Build redundancy: ABB EI813F 24V DC ±10% wide voltage input, redundant power supply module, improve system stability.

Save cabinet space: Compact and modular design, support DIN rail or wall mounting.

Web configuration interface: ABB EI813F realizes the parameterized configuration through the built-in web page, and supports remote maintenance and firmware upgrade, so as to reduce the operation and maintenance complexity.

LED indicators provide real-time status monitoring of the power supply, link status, and data transmission activity to facilitate fault location.

Failure-recovery mechanism: ABB EI813F adopts automatic network failover (supporting redundant configuration), ensuring less downtime.

Industrial automation: Support ABB AC500 PLC remote control and data acquisition to realize production line equipment linkage and robot integration, compatible with Modbus TCP, Profinet and other protocols to seamlessly interface with third-party industrial equipment.

Energy and Power: Adapted to power switchgear and photovoltaic power station real-time data interaction through Modbus TCP protocol to realize equipment interconnection, for wind power / photovoltaic grid control and support redundant network architecture to ensure stability.

Process control: used in chemical and metallurgical industries for reactor temperature regulation and metallurgical equipment status monitoring to adapt to high temperature and dusty environments, in the field of water treatment to realize the pumping unit start/stop and water quality monitoring to adapt to the automation system of wastewater treatment plants.

Railway transportation: It meets EN 50155 standard for railroad signal power management and door control, supports train power system communication, adapts to on-board vibration and -20°C~+60°C wide-temperature environment.

Intelligent Building: Centralized monitoring and energy optimization of HVAC system (air conditioning, lighting) through Modbus TCP, and real-time analysis of energy consumption data can be integrated with intelligent building networking platform.
