Allen Bradley 1746-P1 Output Module
Key SpecificationsVogi
Supply voltage:86-132VAC- 47-63Hz or 180-265VAC- 47-63Hz.
Output voltage 24 VDC
Maximum Output Current: 2 A.
Power Consumption: Typical 135 VA. Peak inrush current: 20 A.
External 24V DC Voltage Input Range: Between 18-30 VDC.
Max Over Current Protection: 15 A
Operating Temperature: -40°C to +60°C.
Storage Temperature: -40°C to +85°C.
Humidity Rating: 5% to 95% non-condensing.
Vibration Resistance (0.05 g rms, 10 to 500 Hz.
Shock Resistance: 5 g, 22 ms half-sine.
Electrical Isolation: 1800V AC rms for 1s
CPU Hold-up Time: 20ms on full load and 3000ms unloaded
Freight Estimation(Part Of The Area)Vogi
|
Destination |
Freight |
|
Middle East |
$35 |
|
Southeast Asia |
$15 |
|
South Asia |
$45 |
|
South Africa |
$37 |
|
Europe and USA |
$24 |
|
Russia |
$42 |
FeaturesVogi
1. LED Status Indicator: The unit has an LED display to provide real-time feedback on system power status, which is useful with troubleshooting and maintenance.
2. CPU Hold-up Time: The system can operate for 20 ms at full load and 3000 ms at no-load before CPU instruction processing gets interrupted, ensuring that no data corruption occurs as a result of a power failure.
3. Short Circuit Protection Circuit: Poly fuse-based short circuit protection mechanism improves system durability and minimises downtime/restarts.
4. System Compatibility: This unit can be applied, through controllers, I/O modules, and other system components, enabling system expansion and integration without any problems.
5. Space-Saving Design: Its compact design allows it to be installed in the space-limited installation and optimizes flexibility in control cabinet layouts.
Applications
Vogi
1. Feed Processing (Animal): Drives power to control systems for crushers, mixers, and conveyors, maintaining productive workflows.
2. Aluminum Smelting Equipment: Provides consistent power to control mechanisms for furnaces and electrolytic cells, enhancing operational reliability.
3. Refrigeration Systems: Empowers critical control components within compressors, condensers, and evaporators, enabling exact temperature control.
4. Combustion Control: Delivers energy to controllers and sensors within industrial combustion systems to help reduce emissions and improve fuel efficiency. Nonferrous Metal Refining Ensures stable handover of power to smelting control, and promotes efficient refining of metal
5. Glass: Fulfils the power demands of control systems in melting furnaces and forming machines, ensuring production quality.
6. Heavy Machinery: Integration with excavator, loader and bulldozer control systems to enhance machinery efficiency and reliability.
7. Textile Production: Drives control circuits on spinning and weaving machines, maintaining operational stability and product quality.
