Foxboro FBM233 P0917HD Ethernet Communication Module
Key SpecificationsVOGI
Power Parameters:
Nominal Voltage: 24 VDC.
Voltage Range: 20 - 30 VDC.
Maximum Voltage: 30 VDC.
Voltage Drop: <1.5VDC.
Power Module Load: <10 watts.
Current Parameters:
Maximum Current Rating: 1.5 mA per channel.
Minimum Required Load: 0 mA.
Load Leakage: 1 mA maximum.
Point Isolation: 2500 VDC.
Input Parameters:
Input Type: TMR (Triple Modular Redundancy), discrete input signals.
Number of Input Signals: 8, isolated and configurable.
Key FeaturesVOGI
Redundant Ethernet Communication: Foxboro FBM233 supports 10/100 Mbps copper Ethernet with dual-port redundancy for high reliability in data transmission ; Enables seamless role switching between Master and Tracker modules during network failures, ensuring continuous operation.
High-Speed Data Integration: Manages up to 2000 DCI blocks, integrating analog/digital signals and third-party device data into control systems like Foxboro DCS or I/A Series; Foxboro FBM233 supports real-time data exchange with 64 external devices via Modbus TCP or other protocols.
Flexible Configuration and Protocols: Software drivers are downloadable from a protocol library, enabling compatibility with diverse third-party devices. Modules can be replaced without system shutdown, minimizing downtime.
