GE DS200TCQAG1BHF RST analog I/O board
Key SpecificationsVogi
1. Processor and Memory:
Processor Type: High performance industrial microprocessor, clock speed up to 150 MHz, facilitating rapid data crunching and execution of control algorithms.
2. Analog Inputs:
Channel Quantity: 12 channels, providing flexibility to connect multiple analog sensors simultaneously.
Input Signal Range: Accommodates 0 - 5V, 0 - 10V, ±5V, ±10V, and 4 - 20mA, catering to a wide variety of sensor output signals.
Accuracy: Achieves an impressive ±0.03% full scale (FS) accuracy, guaranteeing highly precise measurements for critical process control.
3. Analog Outputs:
Channel Number: 8 channels, allowing for control of multiple analog actuators or devices.
Output Signal Range: Can generate 0 - 10V, ±10V, and 4 - 20mA signals, matching the requirements of common industrial equipment.
Accuracy: ±0.05% FS accuracy, ensuring accurate control signals are sent to downstream components.
Resolution: 12-bit resolution, providing 4,096 discrete levels for effective modulation of output.
4. Digital Inputs:
Input Channel Count: 20 channels, with opto-isolated inputs to safeguard against electrical noise and transients.
Input Voltage Levels: Accepts 12 VDC, 24 VDC, and other common industrial voltage standards, widening its compatibility.
Response Time: Ultra fast response time of less than 5 ms, enabling prompt reaction to digital events.
5. Digital Outputs
Output Channel Capacity: 16 channels, mainly relay outputs for driving high-power loads.
Output Specifications: Each relay can handle up to 3 A at 24 VDC or equivalent, making it suitable for directly powering motors, solenoids, and valves.
Switching Time: Quick switching time of less than 8 ms, minimizing latency in actuation.
6. Operating Environment:
Temperature Range: Operates reliably within a wide temperature span of -40°C to 85°C (-40°F to 185°F), making it resilient in both extremely cold and hot industrial settings.
Shock and Vibration Resistance: Complies with stringent industrial shock and vibration standards, safeguarding against mechanical stresses during transportation and operation.
7. Communication Capabilities:
Ethernet Connectivity: Dual 10/100Base-T(X) Ethernet ports, enabling high speed data transfer and seamless integration into Ethernet-based industrial control networks. Supports protocols like TCP/IP, UDP/IP, and Modbus/TCP.
Serial Communication: Incorporates 4 RS-232/485 serial ports, providing backwards compatibility and an alternative communication route for connecting with legacy or specialized equipment that doesn't support Ethernet.
