GE IS200JPDSG1ACB Power Distribution Board

Input Voltage: 28 VDC.

Maximum Input Current: 25 A.

Operating Temperature: -30°C to +65°C.

Mounting: DIN-rail mounting.

Grounding: Established through a sheet metal bracket

Agency Approval: Class 1 Division 2 for explosive atmospheres.

Incorporation of Feedback: GE IS200JPDSG1ACB is capable of incorporating feed-back from PPDA I/O pack and transfer them to PDM system along with the control and monitoring of the power distribution.

Redundancy and Flexibility: GE IS200JPDSG1ACB can maintain three independent 28 V DC power buses internally or combine them into a single internal bus. The both buses support maximum current of 25 A, common ground power supply has 75 A.

Intelligent diagnosis: The built-in intelligent diagnosis function can realize real-time tracking of the power distribution condition, enabling rapid fault detection and solving problems and then improving the efficiency and reliability of the entire system.

Gas turbine control system: In a 660MW gas-steam combined cycle power plant, the IS200JPDSG1ACB module is used to coordinate the combustion control of the gas turbine and the synchronous operation of the steam turbine to ensure that the unit efficiency reaches more than 60%.

Petrochemical production line: In the catalytic cracking unit of the refinery, the module is responsible for monitoring the reactor temperature and pressure, adjusting the valve opening through the PID algorithm, and achieving stable control of product quality.
