HONEYWELL 10300/1/1 Converter Module

 Key SpecificationsVogi

Power input Main power supply: 24VDC ±15%
Backup battery: 12V/7Ah lead-acid battery (supports continuous operation ≥24 hours after power failure).
Communication interface: RS-485/Modbus protocol, supports integration with host computer or BMS system.
Programmable input: 16 dry contacts (voltage-free signal);
Relay output: 8 channels
Device capacity: supports up to 256 detection devices (such as smoke sensors, temperature sensors) or modules.
Operating temperature: -10°C to +55°C;
Humidity range: ≤95% RH (non-condensing).
Display and operation: Liquid crystal display (LCD), supports multi-language menus;
Built-in operation buttons and status indicators.

Functional FeaturesVogi

Signal acquisition and conditioning: 10300/1/1 is able to accurately acquire analog signals from field sensors, in addition to performing signal conditioning operations such as filtering, amplification, and linearization. It significantly improves the quality and reliability of signals by converting raw sensor signals into standard signals that are more in line with the acceptable quality of the control system to eliminate noise or interference, ensuring that the data used for control and monitoring is very accurate.
Data transmission: 10300/1/1 adopts high-speed and stable communication interface technology to ensure that the collected and processed data is transmitted to the control device or central control system on time, thereby ensuring reliable data transmission. This ensures the real-time nature of data integrity and makes it easy to share data, thereby facilitating smooth information transmission between field devices and control centers, which is essential for the normal operation and coordination of any industrial automation control.
Fault diagnosis and alarm: With its internal diagnostic function, HONEYWELL 10300/1/1 can continuously monitor its working status and abnormal functions of input signals. If any fault is found, or the signal is beyond the acceptable range, it will immediately issue an alarm so that relevant personnel can take timely action. This improves the reliability and safety of the system by reducing production losses caused by unnecessary equipment failures.
Configuration flexibility: It has a customizable module that allows users to set parameters, configure channels and customize functions according to specific industrial application requirements with the help of corresponding software tools. That is, it has a very high configurability and can adapt to various control tasks and process flows, which greatly benefits its versatility and applicability in a variety of industrial occasions.

Freight Estimation(Part Of The Area)Vogi

Application AreasVogi

Petrochemical industry; HONEYWELL 10300/1/1 is suitable for extracting and controlling the main working parameters in petroleum refinery and chemical production processes, such as reactor temperature or pressure, pipeline flow rate, etc. In short, it can make precise process measurements and precisely know the “output” situation of the chemical process, it provides technical support for reducing the fluctuation of the production process and ensuring product quality stability, and also provides positive guarantees for effective and reliable operation of petrochemical production system.

Power industry: In power plants, the module in the craftsmanship can be used to monitor the working parameters of generators, transformers and other equipment, such as voltage, current and oil temperature. Thus, enabling to monitor and protect power equipment in real time, which improves the safe and stable power supply of the power system. That is to say, it can also be used for data collection and processing of various electrical quantities in substation automation control systems, which improves the reliability of substation automation systems.
