Schneider 140CRA21210 DIO drop interface Modicon Quantum

Input voltage: 24V DC, voltage range is 20 - 30V DC.

Input current: about 1.6A at 24V.

Surge current: up to 30A at 24V, can withstand the high current shock at startup.

Output voltage: 5.1V.

Nominal output current: 3A, can meet the power requirements of connected devices.

Port situation: 2 redundant single ports to improve communication reliability. If one port fails, the other can continue to maintain communication.

Short circuit protection: can prevent equipment damage caused by short circuit.

Overvoltage protection: ensure stable output voltage to avoid excessive voltage damage to connected devices.

Startup diagnosis: checksum, random access memory (RAM) and its address at startup.

Operation diagnosis: continuously monitor checksum, RAM and address during operation to detect potential faults in time.

Connection method: 7-pole terminal block connection, stable connection and easy installation and maintenance.

Adaptable backplane: It can adapt to typical backplanes with 2, 3, 4, 6, 10, and 16 positions to meet the needs of different system architectures.

Power consumption: The power consumption is about 11W, which is relatively energy-saving.

Buffer time: The buffer time is ≤ 1ms, which can quickly respond to power changes.

Fuse specifications: Equipped with a 2.5A fuse for overcurrent protection.

Protection level: IP20

Operating temperature range: 0°C to 60°C

Humidity range: 10% - 95% RH

High reliability communication: Dual redundant single port design ensures stable communication between I/O devices and control systems, reduces the risk of communication interruption, and ensures continuous operation of industrial automation systems.

Wide voltage adaptability and protection: Schneider 140CRA21210 can work in a wide voltage range, and has short circuit and overvoltage protection, effectively responding to power supply problems and protecting equipment safety.

Real-time diagnostic capability: The diagnostic function during startup and operation can timely detect potential faults, facilitate early maintenance, and reduce downtime.

Flexible adaptability:Schneider 140CRA21210 can adapt to a variety of backplanes, which is convenient for the integration and expansion of industrial automation systems of different scales and architectures.

Energy-saving design: Low power consumption design reduces operating costs and conforms to the trend of green industrial development.

Industrial production line automation:Schneider 140CRA21210 Connect sensors, actuators and other I/O devices on the production line with the control system to achieve automated control and monitoring of the production process and improve production efficiency and quality.

Intelligent warehousing and logistics: In the automated warehousing and logistics system, connect various types of equipment to ensure efficient operation of the cargo storage, handling and transportation process.

Energy management system:Schneider 140CRA21210 Used in energy industries such as electricity, petroleum, and chemicals, connect monitoring and control equipment to ensure the safety and stability of energy production and distribution.

Transportation automation: In the automation system of transportation hubs such as airports and railway stations, connect related equipment to improve the efficiency and reliability of transportation operations.
