Schneider 416NHM30032 Modbus Plus PCI PC adaptor
Key SpecificationsVOGI
Modbus Plus III: supports high-speed peer-to-peer communication (1Mbps), compatible with Modbus RTU/TCP protocol stack.
Protocol features: supports multi-master architecture, supports automatic discovery of network topology, and a maximum number of nodes in a single network segment of 128.
Hardware interface
PCIe interface: adopts PCIe x1 Gen2 standard, supports plug-and-play, and has a data transmission bandwidth of 500MB/s.
Dual-port design: equipped with 2 RJ45 interfaces (with LED status indicators), supporting redundant network connections.
Physical layer: complies with EIA/TIA-568-B standard, supports twisted pair (UTP/STP), and has a transmission distance of up to 1.2km (repeater required).
Power supply specifications
Main power supply: 5V DC ±5%, typical power consumption 1.2W (no load), maximum power consumption 2.5W (full load).
Backup power supply: supports external 12V DC for short-term power supply during fault switching.
Environmental parameters
Operating temperature: -20°C to + 60°C, storage temperature: -40°C to + 70°C.
Humidity range: 5%~95% RH,
Protection level: IP20 certified.
Vibration/shock: Complies with IEC 60068-2-6 standard (10~55Hz, 0.75mm amplitude).
System compatibility
Operating system: Windows 7/10/11 (32/64 bit), Linux (kernel 3.10 and above).
LED indicator
Power: power status (green is always on).
Link/Act: port connection status (green flashing indicates data transmission).
Error: fault alarm (red is always on).
Environmental standards: RoHS 2.0, REACH regulations compliant.
Wiring and configuration
DIP switch: used to set the node address (0~127), communication rate (1Mbps fixed).
Software configuration: Network parameter settings are performed through Modbus Plus Configuration Tool.
Key FeaturesVOGI
High reliability: Dual-port redundancy and industrial-grade environmental adaptability ensure continuous operation of key systems.
Flexible expansion: Multi-master architecture and modular design support complex network topology and equipment expansion.
Efficient integration: Compatible with mainstream protocols and hardware platforms to reduce system integration costs.
Intelligent operation and maintenance: Real-time diagnosis and firmware upgrade functions reduce downtime and maintenance workload.
