WOODWARD 9907-162 Digital Governor Turbine Control

Display Type: Two-line x 24-character LED display.

Enclosure Type: Meets NEMA 4X or IEC 60529 standards, IP56.

Features: Equipped with emergency stop and overspeed test buttons.

Input Voltage: +24 VDC, 1 A.

Keypad/Display: 30-key multi-function keypad.

Operating Temperature Range: -20 to +60 °C.

Outputs: 2 actuator outputs;8 relay outputs;6 programmable current outputs.

Slot Type: Supports RS-232, RS-422, and RS-485 hardware connections.

Software Versions: OpView™ and 505View.

Storage Temperature Range: -40 to +85 °C.

Multi-Function Display and Operator Interface: WOODWARD 9907-162 features LED screen and 30-key function keyboard, allowing setting and monitoring.

Automatic Regulation and Load Control: Automatic speed regulatory and load dropping is done to guarantee even activity of different systems.

Safety Functions: WOODWARD 9907-162 comes with emergency stop, overspeed test and fault alarm to protect the equipment.

Output: WOODWARD 9907-162 has various choices of input/output configurations to adjust to even more needs and RS-232/RS-485 communication.

Operating temperature: WOODWARD 9907-162 is waterproof and dustproof, adapts to the operating temperature of -20°C to +60°C, suitable for industrial environments.

App range: WOODWARD 9907-162 can be widely used for the equipment used can be steam turbine, gas turbine, diesel generators, etc., supporting load sharing and single speed regulation.

Gas Turbine Control: For speed control and load sharing of various gas turbines to ensure smooth operation.

Diesel Generator Sets: For speed regulation of diesel generator sets, especially load sharing when multiple generators are running in parallel.

Hydropower: For turbine control in hydroelectric power plants to achieve precise speed regulation and load distribution.

Power Plants and Industrial Facilities: In large power plants and industrial facilities, Woodward 505 controllers are used for coordination and regulation of multiple engines running in parallel.

Oil and Gas Industry: For oil fields and natural gas facilities to control the speed and load of machinery such as drilling equipment and compressors.

Marine Power Systems: For power system control of ships to ensure stable operation of engines under different loads.

Mining Machinery: For precise speed regulation of mining machinery such as compressors, pumps and transportation equipment.

Other rotating machinery: Widely used in various other mechanical equipment and systems that require precise speed control.
