Yokogawa ATB5S-00 Pressure Clamp Terminal Block Module
Key SpecificationsVOGI
Rated Input Voltage: 24 V DC.
Input On Voltage: 18 - 26.4 V DC.
Input Off Voltage: 5.0 V DC.
Input Current: 4.1 mA ± 20% / channel at rated input voltage.
Maximum Allowable Input Voltage: 30.0 V DC.
Withstanding Voltage: 2 kV AC for 1 minute between input signal and system; 500 V AC for 1 minute between commons (common every 16 - channel).
Input Response Time: 8 ms.
Minimum On Detection Time: 20 ms (for push button input).
Maximum On/Off Cycle: 25 Hz (for push button input).
Key FeaturesVOGI
Fast Signal Processing: Yokogawa ATB5S-00 updates input data every 10 ms for real-time monitoring and control responsiveness.
32-Channel Digital Input Handling: Processes up to 32 discrete digital signals (e.g., switches, sensors) for industrial automation systems like CENTUM VP.
Dual Power Flexibility: Operates with 24 VDC (540 mA max) power inputs for versatile integration.
Wide Load Compatibility: Yokogawa ATB5S-00 supports load resistance ranging from 0–750 Ω, accommodating diverse sensors and devices.
High Dielectric Strength: Withstands 1,500 VAC for 1 minute, ensuring durability in high-voltage conditions.
Freight Estimation(Part Of The Area)VOGI
|
Destination |
Freight |
|
Middle East |
$35 |
|
Southeast Asia |
$15 |
|
South Asia |
$47 |
|
South Africa |
$37 |
|
Europe and USA |
$24 |
|
Russia |
$42 |
APPLICATIONVOGI
Industrial Process Control Systems: Yokogawa ATB5S-00 connects 32-channel digital inputs to Yokogawa CENTUM VP or other control systems for real-time monitoring and automation in manufacturing plants, refineries, or chemical facilities .
Pressure Signal Integration: Links pressure transmitters to Programmable Logic Controllers (PLCs) or Distributed Control Systems (DCS) for data acquisition and process optimization in oil and gas, water treatment, or HVAC systems.
Harsh Environment Automation: Deployed in ISA Standard G3 environments due to its surge protection and vibration-resistant terminals.
Building Automation: Manages digital input signals for HVAC control, fire alarms, or security systems in commercial buildings.
Medical Device Integration: Interfaces with diagnostic equipment or patient monitoring systems requiring secure electrical connections.
Redundant Control Configurations: Supports dual-redundant setups in mission-critical systems to ensure uninterrupted operations.
Legacy System Upgrades: Yokogawa ATB5S-00 is compatible with older Yokogawa systems via bus converters, enabling phased modernization.
